Default How do I straighten a photo?

I thought that it would look "artsy" if I took the picture at an angle. Now I'm not so sure. Can I make it level in photoshop? If so how?

kelso depot

thanks
__________________
feel free to edit my photos, on DPS only

Olympus E-410
14-54 lens , 50-200 lens

flickr
Reply With Quote
  #2 (permalink)
Old 11-07-2007, 05:59 PM
thingy's Avatar
Nifty Fifty

Join Date: Jun 2007
Location: Yarm, UK
Posts: 396
Default

There are probably several methods but one is to click on the Crop tool on your toolbar then hover the mouse outside of the shot and near a corner. Your mouse pointer should change to a curved two headed arrow which you can click and drag your shot around to the desired angle (automatically cropping the required amount).

If you have Lightroom there is a tool within Crop which allows you to draw a line along any edge you wish to make straight (looks like a little ruler).

G
__________________
My Flickr
Reply With Quote
  #3 (permalink)
Old 11-07-2007, 06:00 PM
Marmalade's Avatar
Member

Join Date: Oct 2007
Location: Southern California
Posts: 443
Default

thanks - maybe I should get the "how to" book for photoshop.
__________________
feel free to edit my photos, on DPS only

Olympus E-410
14-54 lens , 50-200 lens

flickr
Reply With Quote
  #4 (permalink)
Old 11-07-2007, 06:04 PM
thingy's Avatar
Nifty Fifty

Join Date: Jun 2007
Location: Yarm, UK
Posts: 396
Default

Well if you do I can personally recommend 'Adobe Photoshop CS3 for Photographers' by Martin Evening. It comes with a DVD too with all the required shot for the video and book exercises. There is also a CS2 version and I believe he is currently outselling the likes of Scott Kelby.

G
__________________
My Flickr
Reply With Quote
  #5 (permalink)
Old 11-07-2007, 06:08 PM
Point & Shoot

Join Date: May 2007
Posts: 13
Default

Here is an easy way a friend just showed me:

In your case I'd use the mountains as your horizon and use the ruler on that.

http://graphicssoft.about.com/cs/pho...straighten.htm
__________________
--------
Nikon D-80 w/18-50mm kit lens, Panasonic Lumix FZ-30
Canon Powershot A540, Minolta XD-11 SLR w/50mm f/1.4, 28mm f/2.8 wide/macro, 85-205 Soligor zoom/macro, Minolta Hi-Matic 9 rangefinder
Reply With Quote
  #6 (permalink)
Old 11-07-2007, 06:08 PM
thingy's Avatar
Nifty Fifty

Join Date: Jun 2007
Location: Yarm, UK
Posts: 396
Default

The other (and more accurate way) which is similar to Lightroom is to use the Measure tool, also available from the toolbar to click and drag along a vertical or horizontal edge that you want straight. Then when you select Image->Rotate Canvas->Arbitrary it should put the angle in from the previous step automatically. You just then have to choose clockwise or counterclockwise.

G
__________________
My Flickr
Reply With Quote
  #7 (permalink)
Old 11-07-2007, 06:16 PM
Marmalade's Avatar
Member

Join Date: Oct 2007
Location: Southern California
Posts: 443
Default

cool thanks - I will play with it when I get home from work tonight.
__________________
feel free to edit my photos, on DPS only

Olympus E-410
14-54 lens , 50-200 lens

flickr
Reply With Quote
  #8 (permalink)
Old 11-07-2007, 11:58 PM
Point & Shoot

Join Date: Jul 2007
Posts: 8
Default picasa

Quote:
Originally Posted by Marmalade View Post
I thought that it would look "artsy" if I took the picture at an angle. Now I'm not so sure. Can I make it level in photoshop? If so how?

kelso depot

thanks
just download picasa free from the internet,
Reply With Quote
  #9 (permalink)
Old 11-08-2007, 12:34 AM
Digital SLR

Join Date: Nov 2007
Location: Midwest
Posts: 54
Default

Just adding my 2 cents for Picasa2. One click straightening

~~
__________________
------------------------------------------
http://www.flickr.com/photos/windowswideopen/
Reply With Quote
  #10 (permalink)
Old 11-08-2007, 12:46 AM
Nicole's Avatar
Super Moderator

Join Date: Dec 2006
Location: Wellington, New Zealand
Posts: 7,657
Default

Or there's the simple way in Photoshop of using the Filter --> Distort --> Lens Correction and then press the button that looks kind of like /_ and drag the line along something that should be straight. That will straighten it out for you. From there, crop it. Easy as pie
__________________
Nikon D90 | Olympus 790SW
Nikkor 18-55mm | Nikkor 70-300mm | Nikkor 50mm f/1.4D
| Lensbaby 2.0 | Nikkor 85mm f/1.8D | Sigma 105mm f/2.8 Macro | Sigma 10-20mm f/4-5.6 | 2xSB600 | Orbis Ring Flash Adapter
My Flickr |
My Shelfari
Reply With Quote
