Default What is your Shutter Actuation Count?

For the EOS Canon users. You can see how many times the shutter actuated using a hex editor and a RAW file.

Tools needed:
- Hex Editor (XVI32 Preferred You can download it here FOR FREE!)
- RAW Image file from your camera

Baiscly what your doing is getting the number located at 95D and 95E and converting it from HEX to DECIMAL. If you do not know exactly how to do this. I will show you below

Step By Step Documentation using Xvi32.

1.) Load Xvi32
2.) Go to Tools>Options>Data Inspector (it's a TAB)
3.) Click "big-endian (MOTOROLA)"
4.) Click "OK" Button to exit out of the options
5.) Go to File>Open>"CHOOSE YOUR RAW IMAGE FILE" then click open
6.) Go to Address>Goto (Or CTRL+G)
7.) Click "Hexadecimal" then TYPE "95D" into the box below
8.) Click "OK"
9.) Then go to TOOLS>DECODE NUMBER
10.) LOOK at "XX XX As Word" (XX Being your numbers located in 95D,E).
11.) The number next to it is your Actuation number.

Here is an example of one of my images


So this is telling me that I took 6149 Pictures.


Note: If you see two sets of Numbers @ 95D+95E don't assume it's that the actuations has it's in HEXADECIMAL and has to be converted to DECIMAL!! CONVERT!

Also I do not know how to do this on other cameras besides the 20D, 30D.
I assume it's on the EOS Series cameras. Not sure about any other.
__________________
Canon 20D W/ 430EX Flash, 50mm F1.8 and 17-40mm F4L Lens

Bail on Flickr, Deviant Art (Friend me!)

Last edited by Bail; 12-20-2006 at 04:13 AM.
Reply With Quote
  #2 (permalink)
Old 12-20-2006, 05:52 AM
googlit's Avatar
Nifty Fifty

Join Date: Dec 2006
Location: Worthington, OH
Posts: 367
Default

If you're running WinXP, you can get Preview Extractor to check the shutter fire count of your Nikon DSLR...

In my brief search, I couldn't find a similar program that runs on Mac or Linux.
__________________
blog :: 28studios.com :: flickr
Reply With Quote
  #3 (permalink)
Old 12-20-2006, 06:11 AM
Nicole's Avatar
Super Moderator

Join Date: Dec 2006
Location: Wellington, New Zealand
Posts: 8,376
Default

Quote:
Originally Posted by googlit View Post
If you're running WinXP, you can get Preview Extractor to check the shutter fire count of your Nikon DSLR...

In my brief search, I couldn't find a similar program that runs on Mac or Linux.
You could try Simple EXIF Viewer for Mac (only seems to work with jpgs though). It says that it reads the shutter actuation, though it wouldn't cooperate with my d50 (maybe Canon people will have more luck with it )
__________________
Nikon D90 | Olympus 790SW
Nikkor 18-55mm | Nikkor 70-300mm | Nikkor 50mm f/1.4D
| Lensbaby 2.0 | Nikkor 85mm f/1.8D | Sigma 105mm f/2.8 Macro | Sigma 10-20mm f/4-5.6 | 2xSB600 | Orbis Ring Flash Adapter
My Flickr |
My Shelfari
Reply With Quote
  #4 (permalink)
Old 12-20-2006, 09:07 PM
googlit's Avatar
Nifty Fifty

Join Date: Dec 2006
Location: Worthington, OH
Posts: 367
Default

Thanks for the tip! I used EXIF Viewer and it worked fine for me—I also use a D50. Here's a screenshot of where it tells you...



I'm up to 13,266.
__________________
blog :: 28studios.com :: flickr
Reply With Quote
  #5 (permalink)
Old 12-21-2006, 12:32 AM
Nicole's Avatar
Super Moderator

Join Date: Dec 2006
Location: Wellington, New Zealand
Posts: 8,376
Default

Quote:
Originally Posted by googlit View Post
Thanks for the tip! I used EXIF Viewer and it worked fine for me—I also use a D50. Here's a screenshot of where it tells you...
I'm up to 13,266.
I think my problem was that iPhoto is eating some of my EXIF data I pulled up an unmodified shot and it was all there. I'm only to half of your shutter actuations googlit (Somewhere around 6500 when I finally got the number)
__________________
Nikon D90 | Olympus 790SW
Nikkor 18-55mm | Nikkor 70-300mm | Nikkor 50mm f/1.4D
| Lensbaby 2.0 | Nikkor 85mm f/1.8D | Sigma 105mm f/2.8 Macro | Sigma 10-20mm f/4-5.6 | 2xSB600 | Orbis Ring Flash Adapter
My Flickr |
My Shelfari
Reply With Quote
  #6 (permalink)
Old 12-21-2006, 07:59 PM
EntityDesigns's Avatar
Point & Shoot

Join Date: Dec 2006
Location: California, USA
Posts: 10
Default

Itried your method it didnt work with my Canon EOS Rebel XT raw files, the easier way to do this is upload your last image onto flickr (making sure you didnt edit the image in any program like photoshop because some programs like photoshop will remove some exif data. Then once it is loaded onto flickr go to the photos page and click "More Properties" on the right side of the page, that will load all the images information my camera has taken 7108 photos.
__________________
----------Signature------------
EntityDesigns.com Web Design
Entity Designs Photog Blog
Reply With Quote
  #7 (permalink)
Old 12-21-2006, 08:19 PM
googlit's Avatar
Nifty Fifty

Join Date: Dec 2006
Location: Worthington, OH
Posts: 367
Default

awesome... I'd forgotten how much EXIF data Flickr pulls down.

Aagh, but it doesn't look like it pulls the actuation count for me (Nikon). oh, well. It's a good first place to look, though.
__________________
blog :: 28studios.com :: flickr
Reply With Quote
  #8 (permalink)
Old 12-21-2006, 09:53 PM
Through the Veil's Avatar
Digital SLR

Join Date: Dec 2006
Posts: 51
Default

Quote:
Originally Posted by googlit View Post
awesome... I'd forgotten how much EXIF data Flickr pulls down.

Aagh, but it doesn't look like it pulls the actuation count for me (Nikon). oh, well. It's a good first place to look, though.
It pulls it off. I use a D50 as well...

Click on more properties...

then go about 3/4 of the way down the gray box...

and find:

Quote:
Total Number of Shutter Releases for Camera:
__________________
Nikon D50 with:
Nikkor 50mm f/1.8D lens; 35-70mm f/3.3-4.5 lens, 70-300mm f/4-5.6 G lens

My Blog: Through the Veil
My flickr
Reply With Quote
  #9 (permalink)
Old 12-21-2006, 10:50 PM
googlit's Avatar
Nifty Fifty

Join Date: Dec 2006
Location: Worthington, OH
Posts: 367
Default

hmm... I don't know what the deal is with mine, but it isn't there. I double-checked. I shoot JPG and usually upload using Flickr Uploadr. Maybe the data is getting eaten somewhere in the transfer... though that seems unlikely to me.

See all the EXIF data that Flickr shows me.
__________________
blog :: 28studios.com :: flickr
Reply With Quote
  #10 (permalink)
Old 12-22-2006, 10:11 AM
Member

Join Date: Dec 2006
Location: Western Massachusetts
Posts: 163
Default

Quote:
Originally Posted by EntityDesigns View Post
Itried your method it didnt work with my Canon EOS Rebel XT raw files, the easier way to do this is upload your last image onto flickr (making sure you didnt edit the image in any program like photoshop because some programs like photoshop will remove some exif data. Then once it is loaded onto flickr go to the photos page and click "More Properties" on the right side of the page, that will load all the images information my camera has taken 7108 photos.
Sorry If I mislead you. I thought it would work on all EOS Series camera with the exception of the Mark 1D which there is a german program that will tell you the info.

I know the method I posted above will work on the 20D for sure. Possibly the 30D too.

Quote:
Originally Posted by googlit View Post
hmm... I don't know what the deal is with mine, but it isn't there. I double-checked. I shoot JPG and usually upload using Flickr Uploadr. Maybe the data is getting eaten somewhere in the transfer... though that seems unlikely to me.

See all the EXIF data that Flickr shows me.
I don't see any shutter count for mine either. I shoot raw, process to JPG (when it comes to the web) and upload. I don't see it.

-----------------------
As for nikon users. I am not sure how you check your actuation count. That's why I posted it in the "Canon" Section, Because it's canon related.
__________________
Canon 20D W/ 430EX Flash, 50mm F1.8 and 17-40mm F4L Lens

Bail on Flickr, Deviant Art (Friend me!)
Reply With Quote
