Default translations

Quote:
Originally Posted by BestRN View Post
Hi,
K10D but as they were out of the kit lens, I got a used-but-in-excellent-shape 67mm Pentax 16-45 DA 1:4 (22) ED-AL wide angle lens. (have NO idea what most of those numbers mean :-)
67mm is the filter size. It's usually not actually used as part of the description of the lens.

16-45 is the focal length range (i.e. zoom range) in millimeters -- one would usually say 16-45mm.

"DA" is Pentax's designation for lenses designed for digital SLRs -- they don't necessarily fill a full film frame (so they can be smaller and lighter), they have designed-for-digital optical coatings, and (unrelated to digital but a feature of all DA lenses) they have a quick-shift features where you can tweak the autofocus manually without switching the body into MF mode.

1:4 is usually the way one specifies magnification, or how good it is at being a macro lens. 1:4 isn't that exciting -- so you know macro isn't really the point of the lens if you see that. (You want 1:2 or better.) But this lens is actually 1:3.8, so either that's just rounded, or more likely, it's a typo for:

f/4 -- this is a constant-aperture zoom, which means the widest aperture of f/4 is available over the entire focal length. The kit lens, by contrast, is "f/3.5 - f/5.6", which means it starts out a fraction of a stop faster at the very wide end, but in the middle is slower and at the telephoto end is much slower. This is a huge advantage of the lens you have -- it makes autofocusing faster, the viewfinder brighter, and allows a narrower depth of field if you want to use selective focus in your composition.

The (22) is the smallest (slowest) aperture the lens can use. 22 is pretty normal. (On a point & shoot camera, by contrast, f/8 is usually the minimum.)

ED means that at least one lens element uses extra-low dispersion glass, which reduces chromatic aberration, so your picture has fewer color artifacts and is sharper.

AL means that at least one lens element is aspherical -- this generally is a part of the design used to reduce distortion, and can replace multiple normal lens elements, making the overall lens smaller and lighter.

So now you know. The upshot is: this is a much better lens than the kit lens.

Quote:
get the zoom for just a little addition of $$ on my part). I probably paid WAY too much for the used lens...but it really does take nice group shots and vistas. However, the zoom quickly became my
Hard to say. The lens is theoretically a little over $400 and then minus a $100 rebate, but it's often hard to find in stock at all. And if it's in good condition, a used lens of this quality will retain most of its original value.
