Photography 101.6 – Shutter

0Comments
Photo 101.6 shutter

Photo: Rainer Ebert used under CC license

The following post is from Australian photographer Neil Creek who just launched a free background image site featuring his photography, and is developing his blog as a resource for the passionate photographer.

Welcome to the sixth lesson in Photography 101 – A Basic Course on the Camera. In this series, we cover all the basics of camera design and use. We talk about the ‘exposure triangle’: shutter speed, aperture and ISO. We talk about focus, depth of field and sharpness, as well as how lenses work, what focal lengths mean and how they put light on the sensor. We also look at the camera itself, how it works, what all the options mean and how they affect your photos.

This week’s lesson is Shutter.

Here’s What We’ve Covered Previously in this Series:

Lesson 1: Light and the Pinhole Camera
Lesson 2: Lenses and Focus
Lesson 3: Lenses, Light and Magnification
Lesson 4: Exposure and Stops
Lesson 5: Aperture

In previous lessons we have talked about the basic theory of how a camera works, including some basic optics, and introduced the idea of exposure and how we control it with the exposure triangle. In this lesson we will be drawing upon what we have learned to understand the second point on the exposure triangle – shutter – and how it works to create your photo.

The Shutter

The shutter’s function in the camera is simply to block light from getting into the camera, unless a photo is being taken, and then to allow light in only for as long as needed to achieve a correct exposure. The name shutter is a little misleading, however. Rather than being a door that opens, and then closes at the end of the exposure, it is more like a gate, with a pair of doors that slide together across the sensor. This arrangement allows for much shorter shutter speeds than could be achieved by moving a single door. The animation below explains this more clearly:


Shutter animation

For the sake of clarity, the above diagram excludes the mirror and all other camera mechanics, only showing the sensor, shutter and some representative surrounds to give a context for the illustration.

When you press the shutter release on the camera, a complex sequence of events occurs, including setting the aperture in the lens, flipping up the mirror of an SLR and a lot more. We’ll just look at the shutter however. So referring to the animation above:

  1. The rear of the two shutter “curtains” as they are called, opens behind the front curtain, and stays up out of the way. At this stage no light has entered the camera, as the front curtain is still closed.
  2. The front curtain drops away, revealing the sensor behind, and allows the light to enter the camera, beginning the exposure.
  3. After a period determined by the set shutter speed, the rear curtain now drops to close the camera to light and end the exposure.
  4. To prepare for the next exposure, the front curtain returns to its normal closed position.

There is an outstanding interactive movie of the inside of a Nikon D3 showing the complete process in incredible detail. I highly recommend taking a look.

Fast Shutter Speeds

When the shutter has been set for a very short exposure period, such as 1/200th sec or faster, the twin curtain system comes into its own. A single “door” shutter wouldn’t be able to open and close this fast. For such short exposures, the rear curtain starts to fall, covering up the sensor before the front curtain is even fully open. The result is a moving open slit passing in front of the sensor. See the animation below:


Fast shutter animation

This method of exposing the sensor (or film) is important when shooting with flash, but the topic of flash sync speed is best covered in another post. In the very early days of photography, when films had poor sensitivity to light, the rolling gap effect of this kind of shutter led to problems with moving subjects, but today there is no disadvantage at all. Most high end DSLRs can achieve incredibly short shutter speeds, such as 1/8000th sec with this shutter design.

The Shutter’s Effect on your Photos

It may seem like your camera is capturing an instant in time, but in reality, it’s capturing a duration of time equal to your shutter speed. This is especially noticeable with long exposures. Anything in the image that is moving while the shutter is open will appear blurred. This also includes the camera itself. Accidental movement of the camera during an exposure is called camera shake and has the effect of smearing the image in the direction of movement. This can be done deliberately for artistic effect, but in most circumstances you’ll want to avoid this.

A good rule of thumb to minimise camera shake is to set the shutter speed at a minimum of one second divided by your focal length. So for example, if you are using a 50mm lens, then to minimise camera shake, you should shoot at 1/50th sec at least. If you are shooting at 200mm, then set the shutter to 1/200th sec. The reason for this is that as we know, longer focal length lenses magnify the image, but they also magnify the camera shake.

Some examples of how choosing your shutter speed can affect your photos:

  • Choose a high shutter speed to freeze motion or action, for example in sport photography.
  • Create the appearance of motion in your photo by choosing slower shutter speed and deliberately controlling camera or subject movement during the shot.
  • A longer exposure on a tripod can make moving water fluffy and white.
  • Very long exposures on a tripod at night can capture very dim scenes, and even stars in the night sky fainter than you can see.

Examples

Wedge Barrel.3
A fast shutter speed freezes the action.
Photo: tylerdurden1 used under CC license
2008 Morse Park Triathlon
Panning with the subject during a long exposure blurs the background and gives the impression of motion.
Photo: indywriter used under CC license

Foamy flow
A slow shutter speed with the camera on a tripod turns river rapids misty white.
Photo: Neil Creek all rights reserved.
The Whole Night Sky
Exposure of 30 seconds or more can capture striking night sky images. In this case, several 30 second images were “stacked”.
Photo: Neil Creek all rights reserved.

Homework

  • Find a fast moving subject – a water fountain is ideal. Photograph it at different shutter speeds, from slow to fast (adjust your aperture to maintain correct exposure), and see what affect it has on the appearance of the subject in the photo.
  • Set your camera to a variety of slow shutter speeds – for example between 1/16sec to 1/2sec – and experiment with moving the camera during the exposure in different ways. Take note of how the different speeds affects the photo, and try exploiting this creatively.
  • Find a moving subject such as cars, or kids on bikes, and shoot them at the same slow shutter speeds – you’ll probably need to do this at dusk or indoors. Pan the camera to keep the subject sharp, and see how the background blur changes at each setting.
  • At night, grab a tripod, or find a stable surface for your camera, and experiment with longer exposures, from one to 30 seconds. Try this with moving subjects such as people at a busy street intersection.
  • Shoot the stars! Take your camera and a tripod away from the city, under some darker skies and point the camera up. A moonless night is best. Use the self-timer or a remote shutter release to minimise camera shake. Set the shutter to 30sec and shoot the stars. Focus can be a challenge, so try auto focusing on a bright star, or use live view zoom to focus if you have it. Here are some of my recent astrophotos.

Resources

Read more from our Tips & Tutorials category

Neil Creek

is a professional photographer from Melbourne, Australia. He has been shooting with a DSLR since 2004, and blogging about his experiences since 2006. Neil has authored five ebooks and a video training course, all designed to help others improve their photography. View Neil’s folio at his home page. Learn about his publications here.
